Part number | Emitting Color | Size | Watt | Lumen | Battery | Work Current |
HS-12cm-WW/PW/CW | WW/PW/CW | 120x40x9mm | 0.6W | 40lm | 300mA | 170mA |
HS-23cm-WW/PW-CW | WW/PW/CW | 230x40x9mm | 1.1W | 90lm | 1100mA | 290mA |
HS-40cm-WW/PW/CW | WW/PW/CW | 400x40x9mm | 2W | 170lm | 1500mA | 500mA |
HS-60cm-WW/PW/CW | WW/PW/CW | 600x40x9mm | 2.6W | 220lm | 2200mA | 720mA |
HS-80cm-WW/PW/CW | WW/PW/CW | 800x40x9mm | 3.3W | 270lm | 3000mA | 880mA |
1. CRI>80.
2. Delay time: 20S +/- 2S.
3. Sensor method: Hand Wave.
4. Sensor degree: 120degree.
5. Sensor distance: Within 5-8cm.
6. Work voltage: 5V
7. Always brightness: about 3hours; Wave Sensor: 1-2month.
The product uses the occlusion or reflection of the detected object to the light beam, and selects the power circuit from the synchronous circuit, so as to detect whether the object exists. The object body is not limited to metal, and all objects that can reflect light can be detected. Photoelectric switch will input current on the transmitter into light signal injection, receiver and then according to the intensity of the received light or have no detection of the target object, so as to control the LED lamp on and off.
1. Using the high quality LEDs,the lighting is soft and comfortable.
2. Non-contact reflective induction, intelligent detection of close reflective objects, automatic switching of working state.
3. Easy to installl,no screws are required,it can be directly attached to the magnet for adsorption.
4. three working modes:OFF/ON/AUTO Switch.
5. Sensor mode: Red color, charging; Green color, full when you charging the lamp.
