48V Extra Long LED Flexible Strips Light

●Adopting high brightness chip, longer lifespan.
●Constant Current Circuit design, from 10 to 60 Meters working length in series connection with one end power supply. Same brightness on both ends.
●Special design, used two constant current channels to increase stability and thermal dissipation.
●Reduced working current at high temperature.

Send email to us

Product Detail

Product Tags

Model No. 48V, 2835 extra long led flexible strips light

● Cut Length:(mm): 50mm for 48V
● Number of LEDs / Meter: 80
● Power (W/M): 5.8W/M
● Input voltage (V) : 48V DC
● CRI：>90
● Beam Angle: 120°
● FPC Width (mm): 10mm
● IP Rate: IP20, IP65, IP67, IP68
● Warranty: 3 years
● Work Environment: -25°～ 45°
● Installation: 3M tape/ Mounting clips/ Aluminum profiles

More available items are below:

LED Type	Kelvin(K)	PCB Widness (mm)	LED Quantity /Meter	Power (W/M)	Brightness(LM/M) @3000k	Light efficiency (LM/W) @3000k	Cutting Size mm	Constant Voltage/ Constant Current	Maximum Length(Meter)
2835	2700K/3000K/4000K/ 6500K	10mm	80	5.8W	534	92	50mm	Constant Voltage	25Meter
2835	2700K/3000K/4000K/ 6500K	10mm	160	8.8W	792	90	25mm	Constant Voltage	20Meter
2835	2700K/3000K/4000K/ 6500K	10mm	72	3.2W	336	105	166.7mm	Constant Current	60Meter
2835	2700K/3000K/4000K/ 6500K	12mm	120	5.2W	541	104	100mm	Constant Current	50Meter
2835	2700K/3000K/4000K/ 6500K	10mm	150	20W	2100	105	100mm	Constant Current	10Meter
2835	2700K+6500K CCT	12mm	240	10.5W	1071	102	100mm	Constant Current	40Meter
5050	RGB	12mm	54	9.4W	427	45.4	166.7mm	Constant Current	50Meter
5050+2835	RGB+W (2700K/3000K/4000K/6500K)	12mm	108	12.5W	655	52.4	166.7mm	Constant Current	40Meter
